Universal Laser Systems

Laser Cutting & Engraving Machines

Innovation and Technology Leadership

Universal Laser Systems, Inc. (ULS) is a global innovation leader in DLMP™ (Digital Laser Material Processing) technology. Universal Laser Systems engraving systems utilize a precise, non-contact process that upholds the integrity of the material even when directed onto small areas. Through innovative technologies and modular components, ULS delivers over 1,000,000 configurations to engrave, cut and mark on a variety of materials - with high precision and speed.

Since 1988, Universal Laser Systems has been improving the application of modern CO2 laser technology. R&D endeavors have resulted in various patents (with several still pending) in a continual pursuit to develop and enhance laser systems that benefit the customer. ULS designs include highly modular platforms that are easily configured with interchangeable laser power cartridges and field upgradeable laser system options. This robust system configuration capability, unique to ULS, gives customers the flexibility and investment protection to optimize laser systems as their needs evolve. Visit Universal Laser Systems to learn more.

*Desktop units are shown on optional air cleaner cart.

  • Universal Laser Systems
    ILS 12.150D
    48" x 24" x 12" Work Area / Dual Laser
    Item Number:
    ILS12.150D

    The ILS12.150D is a free-standing platform with a materials processing envelope of 48" x 24" x 12" or 13,824 in³. The dual laser platform supports a power range of 10 to 150 watts (up to 75 watts with one 10.6µm CO2 laser; up to 150 watts with a second 10.6µm CO2 laser). The ILS12.150D also supports a single 9.3µm laser at 30, 50 or 75 watts (If a 9.3µm CO2 laser is installed, the maximum 10.6µm laser is 75 watts).

  • ILS 12.75 75W Single Laser
    ILS 12.75
    48" x 24" x 12" Work Area / 75W Single Laser
    Item Number:
    ILS12.75

    The ILS12.75 is a free-standing platform with a materials processing envelope of 48" x 24" x 12" or 13,824 in³. The single laser platform supports either one 10.6µm CO2 laser (10 to 75 watts) or one 9.3µm CO2 laser (30, 50 or 75 watts).

  • Dual Laser
    ILS 9.150D
    36” x 24” x 12” Work Area / Dual Laser
    Item Number:
    ILS9.150D

    The ILS9.150D is a free-standing platform with a materials processing envelope of 36” x 24” x 12” or 10,368 in³. The dual laser platform supports a power range of 10 to 150 watts (up to 75 watts with one 10.6µm CO2 laser; up to 150 watts with a second 10.6µm CO2 laser).

  • ILS 9.75 75W Single Laser
    ILS 9.75
    36” x 24” x 12” Work Area / 75W Single Laser
    Item Number:
    ILS9.75

    The ILS9.75 is a free-standing platform with a materials processing envelope of 36” x 24” x 12” or 10,368 in³. The single laser platform supports either one 10.6µm CO2 laser (10 to 75 watts) or one 9.3µm CO2 laser (30, 50, or 75 watts).

  • 150W Dual Laser
    PLS 6.150D
    32" x 18" x 8.5" Work Area / Dual Laser
    Item Number:
    PLS 6.150D

    The PLS6.150D is a free-standing platform with a materials processing envelope of 32" x 18" x 8.5" or 4,896 in³ that supports dual lasers. As a dual laser platform, the PLS6.150 can support up to two 10.6µm CO2 lasers with a power range of 10 watts to 150 watts. Additionally, it can support a single 9.3µm CO2 of 30, 50 or 75 watts. (if a 9.3µm CO2 laser is installed, only one 10.6µm CO2 of up to 75 watts may be installed at the same time.)

  • Fab Lab Laser Cutter
    ULTRA R5000
    32” x 24” Work Area / Configure with up to two laser sources (two interchangeable CO2 lasers or one CO2 laser and one fiber laser)
    Item Number:
    ULTRA R5000

    Tech-Labs technical training solutions.

  • Universal Laser Systems
    ULTRA R9000
    48” x 24” Work Area / Configure with up to two laser sources (two interchangeable CO2 lasers or one CO2 laser and one fiber laser)
    Item Number:
    ULTRA R9000

    The ULTRA R9000 platform offers laser material processing for a wide range of materials. It is designed and ideally suited for material processing in manufacturing, research and development, academic research, and prototyping environments. With its unique modular architecture, customizable solutions can be easily reconfigured with a wide array of options for enhancing performance, capability, and safety to complete the perfect solution to meet present and future business needs.

  • Laser Engraving Machine
    ULTRA X6000
    48” x 24” Work Area / Configure with up to two laser sources (two interchangeable CO2 lasers or one CO2 laser and one fiber laser)
    Item Number:
    ULTRA X6000

    The ULTRA X6000 platform offers laser material processing for the widest possible range of materials. It is designed and ideally suited for precision material processing in manufacturing, research and development, academic research, and prototyping environments. With its unique modular architecture, customizable solutions can be easily reconfigured with a wide array of options for enhancing performance, capability, and safety.

  • 16” x 12” Work Area
    VLS 2.30DT
    Compact, Entry-Level Platform
    Item Number:
    VLS 2.30DT

    The VLS2.30DT Desktop is a compact and economical entry-level platform. It offers a material processing envelope of 16" x 12" x 4" or 768 in³ and can be equipped with one 10.6µm CO2 laser source ranging in power from 10 to 30 watts or one 9.3µm CO2 30 watt laser source.

  • Laser Cutting & Engraving Machines
    VLS3.60DT
    24” x 12” x 4" Work Area
    Item Number:
    VLS3.60DT

    The VLS3.60DT is a compact and economical entry-level platform that offers a material processing envelope of 24" x 12" x 4" or 1,152 in³. The VLS3.60DT can be equipped with one of five 10.6µm CO2 laser sources ranging in power from 10 to 60 watts or one 9.3µm CO2 30 watt or 50-watt laser source.
